MMBZ27VALT1G: Precision Zener Diode for Voltage Regulation and Protection
Release time：May 12, 2025
Views：76
In the world of compact electronics and sensitive circuits, protection and voltage regulation are critical. The MMBZ27VALT1G, manufactured by onsemi (formerly ON Semiconductor), is a dual Zener diode array designed to offer reliable clamping and regulation for low-voltage applications. With its compact SOT-23 package and precise electrical characteristics, this device is widely used in both consumer and industrial systems where overvoltage protection or voltage reference is required.
Technical Specifications
- Device Type: Dual Zener diode (common cathode configuration)
- Zener Voltage (Vz): 27V
- Power Dissipation: 350 mW
- Working Voltage Range: ±24V typical
- Zener Tolerance: ±5%
- Package: SOT-23 (Surface-Mount Technology)
- Configuration: Dual Zener, common cathode
- Polarity: Bidirectional clamping (when used in reverse orientation)
- ESD Rating: High-level protection
- Operating Temperature Range: –65°C to +150°C
Key Features
- Compact Footprint – The SOT-23 package enables dense PCB layouts in space-constrained applications.
- Accurate Voltage Clamping – 27V breakdown voltage with ±5% tolerance for precise voltage regulation.
- Dual Zener Configuration – Provides flexible protection for both unidirectional and bidirectional voltage conditions.
- Low Leakage Current – Ensures minimal impact on sensitive analog and digital circuits.
- Thermal Stability – Designed for consistent performance over a wide temperature range.
- RoHS & REACH Compliant – Environmentally safe and suitable for global markets.
Typical Applications
The MMBZ27VALT1G is widely adopted across multiple industries for its role in protecting sensitive circuitry and regulating voltage in embedded systems:
- Consumer Electronics
- Automotive Electronics
- Industrial Control
- Communications Equipment
- IoT Devices and Embedded Systems
Why Source MMBZ27VALT1G from Sunether?
- Ready-to-Ship Inventory – We maintain stock of the MMBZ27VALT1G for fast fulfillment, even during market shortages.
- Competitive Pricing – Our global sourcing network allows us to provide cost-effective solutions to keep your BOM optimized.
- Fast Global Delivery – With logistics hubs in Asia, Europe, and North America, we guarantee on-time shipping to meet tight development schedules.
- Professional Support – Our experienced sales and engineering teams offer technical guidance, cross-reference support, and customized sourcing solutions.
- Reliable Quality – All parts undergo strict quality control and are fully traceable, ensuring peace of mind for procurement and engineering teams.
- Flexible MOQs – We support orders of all sizes, whether you’re building a prototype or ramping into production.
With Sunether as your sourcing partner, you not only gain access to this high-quality component at competitive prices, but also benefit from our fast delivery, technical support, and world-class customer service.Contact Sunether today to check stock availability, request a quote, or get technical support for your next project!
