NCV7707DQR2G: Robust Hex Half-Bridge Driver for Automotive Mechatronics
Release time：Jul 8, 2025
Views：96
As automotive systems become increasingly electrified and intelligent, the demand for compact, reliable, and integrated motor driver ICs is on the rise. The NCV7707DQR2G, developed by onsemi, is a hex half-bridge driver designed for automotive body control and mechatronic systems, offering a robust solution for controlling DC motors, actuators, and relays.With its high level of integration and built-in safety diagnostics, the NCV7707DQR2G delivers efficiency, space savings, and functional safety—all key in next-generation automotive designs.
Key Specifications
- Type: Hex Half-Bridge Driver (6 outputs)
- Supply Voltage: 5.5V – 18V
- Output Current: Up to 1.0 A per channel
- Low RDS(on): 0.6 Ω typical
- Control Interface: Serial SPI (4-wire)
- Operating Temperature: –40°C to +150°C
- Package: SSOP-24 EP (Exposed Pad for thermal performance)
- Qualification: AEC-Q100 Grade 0
- RoHS & REACH Compliant: Yes
Product Features & Benefits
- Integrated 6-Channel Driver – Drives multiple loads (motors, solenoids, relays) with one compact IC, reducing component count.
- SPI Control & Diagnostics – Offers simple interface with MCU and real-time fault monitoring, ideal for safety applications.
- Built-in Protection – Thermal shutdown, short-circuit, and open-load diagnostics protect both IC and the system.
- Flexible Drive Configurations – Each output can be used independently or configured in H-bridge mode for bidirectional motor control.
- Automotive-Grade Reliability – Fully qualified for harsh environments and extended temperature operation.
Application Scenarios
- The NCV7707DQR2G is a versatile IC suited for a wide range of automotive body and comfort applications, including:
- Door Module Control Units
- Power Seat Adjusters
- Mirror Positioning Systems
- HVAC Actuator Control
- Sunroof & Window Lift Motors
- Central Locking Mechanisms
- Electronic Parking Brake Control
Why Source NCV7707DQR2G from Sunether?
At Sunether, we combine decades of semiconductor industry experience with a global supply network to offer the NCV7707DQR2G with unmatched sourcing advantages:
- Ready-to-Ship Inventory – We maintain in-stock supply of NCV7707DQR2G, supporting fast turnaround on your orders.
- Competitive Pricing – Our strong sourcing relationships and volume leverage allow us to offer cost-effective quotes, even in tight markets.
- Fast Global Delivery – Orders ship same day or next day, with reliable tracking and logistics support worldwide.
- Authentic Quality Assurance – All parts are genuine, with full traceability and inspection from certified sources.
- Flexible MOQs – We support projects of all sizes, from prototype development to full-scale production.
- Professional Support – Our team provides technical documentation, BOM cross-referencing, and responsive customer service.
When sourcing from Sunether, you get not just the part—but a sourcing partner that ensures efficiency, competitive pricing, and world-class support.📩 Reach out to Sunether today for a quote, availability check, or engineering support with the NCV7707DQR2G and other high-performance automotive ICs.
