UCC21520DWR
| Part No.: | UCC21520DWR |
| RoHs Status: | RoHS Compliant |
| Manufacturer/Brand: | Texas Instruments |
| Stock Condition: | In stock:3648 |
| Description: | DGTL ISO 5.7KV 2CH GT DVR 16SOIC |
| Ship From: | Hong Kong |
| Datasheets: | |
| Shhipment Way: | DHL/Fedex/TNT/UPS/EM |
| Ladder Price: | 1+ $4.36 2000+ $2.1895 |
| Recent price fluctuations have been significant. By inquiring now, you may get a price up to 50% lower than expected. |
WARM TIPS
- Product parameters show on this page may contain errors. Please refer to datasheet for specific product information.
- Please contact our sales staff for a real-time quotation as our website may not reflect the latest information on all products. The final price is subject to the inquiry result.
REQUEST QUOTE
Please fill in all required fields and click "
SUBMIT REQUEST"
| *Part No. | UCC21520DWR |
| *Quantity | |
| Target Price(USD) | |
| Company Name | |
| *Contact Name | |
| *Your Email | |
| Phone | |
| Message | |
| *Company Type | OEM/CEM Distributor/Reseller Others |
Submit Request | |
Part No.
UCC21520DWR
Operating Temperature
-40°C ~ 125°C
Rise / Fall Time (Typ)
6ns, 7ns
Common Mode Transient Immunity (Min)
100V/ns
Voltage - Isolation
5700Vrms
Approval Agency
CQC, CSA, UR, VDE
Mounting Type
Surface Mount
Product Status
Active
Supplier Device Package
16-SOIC
Pulse Width Distortion (Max)
6ns
Package / Case
16-SOIC (0.295", 7.50mm Width)
Number of Channels
2
Technology
Capacitive Coupling
Voltage - Output Supply
6.5V ~ 25V
Package
Tape & Reel (TR);Cut Tape (CT);Digi-Reel®
Propagation Delay tpLH / tpHL (Max)
30ns, 30ns
Current - Output High, Low
4A, 6A
