NCV7703CD2R2G
| Part No.: | NCV7703CD2R2G |
| RoHs Status: | RoHS Compliant |
| Manufacturer/Brand: | onsemi |
| Stock Condition: | In stock:4584 |
| Description: | IC HALF BRIDGE DRVR 1.1A 14SOIC |
| Ship From: | Hong Kong |
| Datasheets: | |
| Shhipment Way: | DHL/Fedex/TNT/UPS/EM |
| Ladder Price: | 1+ $2.68 2500+ $1.1817 |
| Recent price fluctuations have been significant. By inquiring now, you may get a price up to 50% lower than expected. |
WARM TIPS
- Product parameters show on this page may contain errors. Please refer to datasheet for specific product information.
- Please contact our sales staff for a real-time quotation as our website may not reflect the latest information on all products. The final price is subject to the inquiry result.
REQUEST QUOTE
Please fill in all required fields and click "
SUBMIT REQUEST"
| *Part No. | NCV7703CD2R2G |
| *Quantity | |
| Target Price(USD) | |
| Company Name | |
| *Contact Name | |
| *Your Email | |
| Phone | |
| Message | |
| *Company Type | OEM/CEM Distributor/Reseller Others |
Submit Request | |
Part No.
NCV7703CD2R2G
Operating Temperature
-40°C ~ 150°C (TJ)
Applications
DC Motors, General Purpose
Output Configuration
Half Bridge (3)
Load Type
Inductive
Voltage - Load
5.5V ~ 40V
Mounting Type
Surface Mount
Rds On (Typ)
800mOhm LS, 800mOhm HS
Product Status
Active
Supplier Device Package
14-SOIC
Fault Protection
Current Limiting, ESD, Over Temperature, Over Voltage, UVLO
Package / Case
14-SOIC (0.154", 3.90mm Width)
Technology
Power MOSFET
Voltage - Supply
3.15V ~ 5.25V
Package
Tape & Reel (TR);Cut Tape (CT);Digi-Reel®
Current - Output / Channel
1.1A
Interface
SPI
